CMSC250

Logic

Logic

Recap: Statements
Operations
Truth Tables and Equivalence

Statements

Statement: a declarative sentence with a truth value

ie. A sentence that is either true or false, but not both

Aristotle's work founded Aristotelian logic

Discrete Math has no applications to CS

\[2 + 2 = 4\]

\[1 + 1 = 0\]

They are not opinions

C is better programming language than Java

They are not meaningless

Colorless green ideas sleep furiously

Must be defined

\[x > 30\]

Must be defined

let \(x\) be the number of students in class

\[x > 30\]

Statements variables are denoted as a lowercase letter

\[x > 30\]

\(y\): there are more than 30 students in the class

Operations

Statements can be modified and combined

  • Negation: \(\neg, {\sim}, \bar p\)
  • Conjunction: \(\land\)
  • Disjunction: \(\lor\)
  • Implication: \(\Rightarrow\)

Negation

I have graduated highschool

I have not graduated highschool

!(I have graduated highschool)

~(I have graduated highschool)

\(p: 2 + 2 = 4\)

~\(p:\)~\(( 2 + 2 = 4)\)

\(p: 2 + 2 = 4\)

~\(p:\)~\(( 2 + 2 = 4)\)

\[ \text{~}p = \begin{cases} \text{true} & \text{if } p \text{ is false}\\ \text{false} & \text{if } p \text{ is true}\\ \end{cases} \]

Conjunction

\(p\): Tomorrow will be cloudy

\(q\): Tomorrow will be sunny

Tomorrow will be cloudy and sunny

\(p\) && \(q\)

\(p \land q\)

\(p\): Tomorrow will be cloudy

\(q\): Tomorrow will be sunny

\(p \land q\)

\[ p \land q = \begin{cases} \text{true} & \text{if both of } p \text{ and } q \text{ is True}\\ \text{false} & \text{if one or both of } p \text{ and } q \text{ is false}\\ \end{cases} \]

\(p\): \(2 + 2 = 4\)

\(q\): \(4 + 2 = 6\)

\(p \land q\)

\(p\): \(2 + 2 = 5\)

\(q\): \(1 + 2 = 3\)

\(p \land q\)

Disjunction

\(p\): Tomorrow will be cloudy

\(q\): Tomorrow will be sunny

Tomorrow will be cloudy or sunny

\(p || q\)

\(p \lor q\)

\(p\): Tomorrow will be cloudy

\(q\): Tomorrow will be sunny

\(p \lor q\)

\[ p \lor q = \begin{cases} \text{true} & \text{if one or both of } p \text{ and } q \text{ is true}\\ \text{false} & \text{if } p \text{ is false and } q \text{ is false}\\ \end{cases} \]

\(p\): \(2 + 2 = 4\)

\(q\): \(4 + 5 = 1\)

\(p \lor q\)

\(p\): \(2 + 2 = 5\)

\(q\): \(1 + 2 = 4\)

\(p \lor q\)

Note: Logical OR is not the same as English OR

I am younger than 50 or I am at least 50

I am having fun or I am causing chaos

Note: Logical OR is not the same as English OR

I am younger than 50 \(\oplus\) I am at least 50

I am having fun \(\lor \) I am causing chaos

Note: Logical OR is not the same as English OR

I am younger than 50 \(\oplus\) I am at least 50

I am having fun \(\lor \) I am causing chaos

\(\oplus\) is exclusive or

Can make with and, or and not so we will not be using them in this class

\(\oplus\) is exclusive or

Can make with and, or and not so we will not be using them in this class

\(p \oplus q\):\((p \lor q) \land ({\sim}(p \land q))\)

Implication

\(p\): I throw a ball

\(q\): The window will break

\(p \Rightarrow q\)

This is not causal

This is not causal

\(p\): The sky is blue

\(q\): 2 + 2 = 4

\(p \Rightarrow q\)

Conditionals are tricky

They are true if the antecedent is false \(\lor\) the consequent is true

Truth Tables can help visualize this

Truth Tables and Equivalence

We may want to make really long statements

Truth Tables

\(p\) ~\(p\)
0 1
1 0
\(p\) \(q\) \(p \lor q\)
0 0 0
0 1 1
1 0 1
1 1 1
\(p\) \(q\) \(p \land q\)
0 0 0
0 1 0
1 0 0
1 1 1
\(p\) \(q\) \(p \Rightarrow q\)
0 0 1
0 1 1
1 0 0
1 1 1

Think of this as a promise between \(p\) and \(q\)

\(p\) \(q\) \(p \Rightarrow q\)
0 0 1
0 1 1
1 0 0
1 1 1

\((p \Leftrightarrow q) \equiv ((p \Rightarrow q)\land(q \Rightarrow p)\)

Read as: p iff q, p if and only if q

\(p\) \(q\) \(p \Rightarrow q\)
0 0 1
0 1 1
1 0 0
1 1 1

We can rewrite with \(\land,\lor,{\sim}\): \(({\sim}p) \lor q\)

\(p\) \(q\) ~\(p\) \({(\sim}p) \lor q\)
0 0 1 1
0 1 1 1
1 0 0 0
1 1 0 1
\(p\) \(q\) \(r\) \(p \lor q\) ~\(r\) \((p \lor q) \land (\)~\(r)\)
0 0 0 0 1 0
0 0 1 0 0 0
0 1 0 1 1 1
0 1 1 1 0 0
1 0 0 1 1 1
1 0 1 1 0 0
1 1 0 1 1 1
1 1 1 1 0 0

Equivalence

Note: Two statements \(p\) and \(q\) are logically equivalent \((p \equiv q)\)when they have the same T/F value for all value combinations

Note: Two statements \(p\) and \(q\) are logically equivalent \((p \equiv q)\)when they have the same T/F value for all value combinations

ie. They have the same truth table

\(p \equiv\)~\((\)~\(p)\)

\(p\) ~\(p\) ~\((\)~\(p)\)
0 1 0
1 0 1

\((p \Rightarrow q) \equiv (({\sim}p) \lor q)\)

\(p\) \(q\) \(\sim p\) \(p \Rightarrow q\) \((({\sim}p) \lor q)\)
0 0 1 1 1
0 1 1 1 1
1 0 0 0 0
1 1 0 1 1

\((p \Rightarrow q) \equiv (({\sim}p) \lor q)\)

\((p \Rightarrow q) \equiv(q \Rightarrow p)\)?

\((p \Rightarrow q) \equiv(({\sim}p) \Rightarrow ({\sim}q))\)?

\((p \Rightarrow q) \equiv(({\sim}q) \Rightarrow ({\sim}p))\)?

\((p \Rightarrow q) \equiv (({\sim}p) \lor q)\)

\((p \Rightarrow q) \equiv(q \Rightarrow p)\)?

(converse)

\((p \Rightarrow q) \equiv(({\sim}p) \Rightarrow ({\sim}q))\)?

(inverse)

\((p \Rightarrow q) \equiv(({\sim}q) \Rightarrow ({\sim}p))\)?

(Contrapositive)

\((p \Rightarrow q),(q \Rightarrow p),(({\sim}p)\Rightarrow {\sim}q), (({\sim}q) \Rightarrow ({\sim}p))\)

\(p\) \(q\) \(p \Rightarrow q\) \(q \Rightarrow p\) \(({\sim}p) \Rightarrow ({\sim} q)\) \(({\sim}q) \Rightarrow ({\sim} p)\)
0 0 1 1 1 1
0 1 1 0 0 1
1 0 0 1 1 0
1 1 1 1 1 1

~\((p \lor q) \equiv (\)~\(p)\land (\)~\(q)\)

~\((p \lor q) \equiv (\)~\(p)\land (\)~\(q)\)

\(p\) \(q\) ~\(p\) ~\(q\) \(p \lor q\) ~\((p \lor q)\) \((\)~\(p)\land(\)~\(q)\)
0 0 1 1 0 1 1
0 1 1 0 1 0 0
1 0 0 1 1 0 0
1 1 0 0 1 0 0

~\((p \lor q) \equiv (\)~\(p)\land (\)~\(q)\)

~\((p \land q) \equiv (\)~\(p)\lor (\)~\(q)\)

Note: These together are known as DeMorgan's Laws

Note a few special Cases

Note a few special Cases

\(p\) ~\(p\) ~\(p \lor p\)
0 1 1
1 0 1

Tautology

\(p\) ~\(p\) ~\(p \land p\)
0 1 0
1 0 0

Contradiction
